DOTQ - IP54 Battery LED dot 15°, Crome

Name: DOTQ - IP54 Battery LED dot 15°, Crome
Brand: Prolights

Battery LED dot, 1x15W RGBW/FC, WDMX, 6h-14h autonomy, IP54, 0,6 kg, 15°, MR

Description Specification Brand information Downloads

DotQ is an ultra-compact, wireless, battery LED accent luminaire designed to light up the entirety of the inside or outside of a room. The compact form factor and chrome finish allows it to be used anywhere that needs a 'little lift' to finish off the perfect event design.

Technical Specifications

LIGHT SOURCE

Source: 15W RGBW LED
Luminous flux: 550lm
Lux: 710lx @3 m full
Source life expectancy: > 50.000 h

OPTICS

Beam angle: 15°
Field angle: 23°
Additional optics: magnetic frost filter included for wider diffusion

COLOUR SYSTEM

Colour mixing: RGBW / FC
White presets: 2.800 K - 9.000K
Colour wheel: virtual colour wheel with macros
Macros: built-in white presets

DYNAMIC EFFECTS

Static mode: selection of static colour
Manual mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment

BODY

Hardware on-board: frost, foots, IR, charger, bracket
Tilt angle: ° adjustable foot support for tilt regulation (up to 20°)
Body: sturdy policarbonate body
Body colour: mirror finishing

CONTROL

Protocols: W-DMX, RDM
DMX channels: 5 / 9channel
W-DMX: included, wireless solution receiver
RDM: RDM for remote monitoring and settings
Display: 3 chars display
IR: infrared remote controller for simple control, addressing and settings

ELECTRONICS

Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Operating temperature: 0° ~ +35°
LED Control: flicker free operation

ELECTRICAL

Mains power supply: 100-240V - 50/60Hz

BATTERY

Battery: 11,1V lithium
Estimated battery life in colour change mode up to: 10h
Estimated battery life in single colour mode up to: 15h
Estimated battery life in full-mode up to: 5h
Re-charge connection: power cable
Re-charge time: 3h/max
Battery status: LED battery status indicator

PHYSICAL

IP rating: for temporary outdoor use - IP65 (front) - IP54 (bottom)
Cooling: passive cooling and fan-free
Suspension and fixing: bracket for hanging and positioning
Dimensions (WxHxD): 102x120x105mm
Weight: 0,6kg

Supplier SKU

DOTQMR
